DIAGRAMS
FUSE POSITIONS
SR 1800C D
(See Fig. AG)
1. Solenoid valve+flashing light: 10 A
2. Stop: 7.5 A
3. Free: 7.5 A
4. Filter shaker: 10 A
5. Horn: 7.5 A
6. Free: 7.5 A
7. Free: 20 A
8. Free: 10 A
9. Free: 10 A
10. Free: 20 A
11. Diesel solenoid valve: 7.5 A
12. Dashboard: 7.5 A
13. Hazard warning lights: 10 A
14. Left running lights: 7.5 A
15. Low beam: 10 A
16. High beam: 10 A
17. Right running lights: 7.5 A
18. Turn signals: 10 A
SR 1800C B
(See Fig. AH)
1. Dashboard+horn: 7.5 A
2. Free: 7.5 A
3. Free: 7.5 A
4. Hour counter: 7.5 A
5. Free: 10 A
6. Motor safety device: 10 A
7. Blower: 20 A
8. Free: 10 A
9. Filter shaker: 20 A
10. Motor overtemperature relay: 7.5 A
11. Free: 7.5 A
12. Free: 7.5 A
13. Turn signals: 7.5 A
14. Hazard warning lights: 7.5 A
15. Left running lights: 7.5 A
16. Low beam: 10 A
17. High beam: 10 A
18. Right running lights: 7.5 A
WIRING DIAGRAMS
SR 1800C D
(See Fig. AI)
A: 12 V-45 A alternator
AA: Horn
B:
12 V-80 A battery
B1: Glow plug bulb
B2: Engine oil bulb
B3: Engine water bulb
B4: Parking brake micro-switch
B5: Air cleaner bulb
B6: Fuel level indicator
B7: Blower bulb
B8: Seat safety micro-switch
B9: Reverse gear sensor
B10: Bimetallic thermostat
CO: Hour counter
C1: Ignition switch
C2: Glow plug control unit
C3: Combination switch
C4: Hazard warning light switch
C5: Reverse gear buzzer
C6: Reverse gear alarm buzzer
D1: 1N4007 diode
EV1: Diesel solenoid valve
F1: Turn signal fuse
F2: Hazard warning light fuse
F3: Left side running light fuse
F4: Right side running light fuse
F5: High beam fuse
F6: Low beam fuse
F7: Diesel solenoid valve fuse
F8: Indicator/warning light fuse
F9: Brake light fuse
F10: Free
F11: Skirt sensor fuse
F12: Blower
fuse
F13: Free
F14: Filter shaker fuse
F15: Skirt warning light relay fuse
F16: Free
F17: Revolution safety relay fuse
F18: Horn
fuse
I: Flashing device
