HP Pantalla LED de 55 pulgadas HP LD5535 Digital Signage - Manual (Page 90)

27. Tile ID Set d I Refer to ‘Tile ID’
28. Tile H Position d e 00 to 14
29. Tile V Position d f 00 to 14
30. Tile H Size d g 00 to 32
31. Tile V Size d h 00 to 32
32 Natural Mode (In Tile Mode) d j 00 to 01
33. DPM Select f j 00 to 01
34. Temperature Value d n FF
35. Remote Lock/Key Lock k m 00 to 01
36. Key (not supported) m c Refer to ‘Key’
37. OSD Select k l 00 to 01
38. Operating Time d l FF
39. Serial No f y FF
40. S/W Version f z FF
41. Backlight m g 00 TO 64
42. Display Name v a FF
43. Abnormal State k z FF
44. Display Location v b FF
45. Player Name v d FF
46. DHCP (VOE) v e FF
47. Scheduling Input Select f u Refer to ‘Scheduling Input Select’
48. IP Address (VOE) v f FF
49. Auto Off f g 00H to 01H
50. Subnet Mask (VOE) v g ffH
51. IP Address (NSM) v k ffH
52. Mac Address (VOE) v h ffH
53. Check VOE Availability v I ffH
54. Mac Address (NSM) v j ffH
55. Product Name f v ffH
56. Subnet Mask (NSM) f v FF
NOTA: During USB operations such as EMF, all commands except Power(k a) and Key(m c) are
not executed and treated as NG.
80 Capítulo 12 Control de múltiples productos
