6
HP Smart Array P600 Controller for Integrity Servers User Guide
*Ports 1E and 1I share electrical circuitry. Whenever the controller is reset, it searches for
devices connected to port 1E before searching on port 1I. If both these ports are
connected to storage devices, the controller discovers and uses only the devices attached
to port 1E. Devices connected to port 1I are not displayed in this case.
Controller specifications
Feature Details
Card type
Full-length PCI-X 133
Dimensions (excluding bracket)
31.1 cm x 10.8 cm x 1.8 cm (12.3 in x 4.3 in x 0.7 in)
Power required
Approximately 28 W
Temperature range
Operating, 10° to 35°C (50° to 95°F); storage, -20° to 55°C (-4° to
131°F)
Relative humidity
(noncondensing)
Operating, 10% to 70%; storage, 5% to 90%
RAID levels supported
0, 1, 1+0, 5, ADG (also called RAID 6)
Connector type
Compatible with full-length 3.3-V, 64-bit PCI-X or PCI slot
Transfer rate
Up to 1.0 GB/s at 133 MHz (64-bit)
Number of SAS ports
2 (1 internal, and 1 that can be used as internal or external)
SAS transfer rate
Up to 1.2 GB/s per port in each direction
For more information about the controller features and specifications, and for
information about system requirements, refer to the HP website
(
