Installation
Unpacking
All transit bolts and packing must be removed before using the appli-
ance.
After removing all the packaging, carefully
lay machine on it’s back to remove the poly-
styrene base from the bottom.
Remove the power supply cable and the
draining hose from the hose holders on the
rear of the appliance.
With a suitable
spanner, supplied
with the machine
unscrew and
remove the cen-
tral rear bolt A.
Slide out the rel-
evant plastic
spacer.
Unscrew and
remove the two
large rear bolts B
and the six smaller
bolts C.
Remove the
bracket D. Tight-
en up the six
smaller bolts C.
Open the port-
hole, take out the
inlet hose from the
drum and remove
the polystyrene
block fitted with
the adhesive tape
on the door seal.
42
HEC0008
HEC0002S
A
HEC0001
HEC0011S
D
C
C
B
HEC0003S
B
C
C
HEC0014 HEC0010
