TPC-1260 User's Manual
1.4 Touchscreen specifications
1.5
Power
- Input voltage: 24V
DC
(the fuse will be open circuit as input level
exceeds 33V
DC
)
- Maximum current: 2 A
1.6
I/O ports arrangement
The TPC-1260 has 4 serial ports, 1 parallel port, 1 USB port, 2 PS/2
ports, 1 RJ-45 LAN port and a PC/104+ expansion slot. The arrange-
ment of these ports is shown in Figure 1.6-1.
