ASUS M2N-MX SE PLUS 2-15
2.3.4 IDE Configuration
The items in this menu allow you to set or change the configurations for the IDE
devices installed in the system. Select an item then press if you wish to
configure the item.
IDE Configuration
Onboard IDE Controller [Enabled]
Serial-ATA Devices [Enabled]
nVidia RAID Function [Disabled]
Onboard IDE Controller [Enabled]
Allows you to enable or disable the onboard IDE controller.
Configuration options: [Enabled] [Disabled]
Serial-ATA Devices [Enabled]
Allows you to disable or set the Serial-ATA devices.
Configuration options: [Disabled] [Enabled]
nVidia RAID Function [Disabled]
Allows you to enable or disable the NVIDIA RAID function.
Configuration options: [Enabled] [Disabled]
2.3.5 Primary IDE Master/Slave
While entering Setup, the BIOS automatically detects the presence of IDE devices.
There is a separate sub-menu for each IDE device. Select a device item then
press to display the IDE device information.
Primary IDE Master
Device : Not Detected
Type [Auto]
LBA/Large Mode [Auto]
Block(Multi-sector Transfer) M [Auto]
PIO Mode [Auto]
DMA Mode [Auto]
SMART Monitoring [Auto]
32Bit Data Transfer [Enabled]
Disabled: disables
the integrated IDE
Controller.
Enabled: enables
the integrated IDE
Controller.
Select the type
of device connected to
the system.
