For further information contact ups direct ltd – APC 208 Vac User Manual
Page 10
For further information contact UPS Direct Ltd:
Tel: 08456 445 002 - Fax: 08456 445 003 - Email: [email protected] - Website: www.upsdirect.com
6
Smart-UPS 5000 VA 208/230 Vac Tower/Rack-Mount 5U User Manual
Connect batteries
Configure bezel
Snap the display out of the bezel. Rotate the bezel and reinstall the display for a tower configuration.
After all of the batteries have been connected, tuck the battery cables and the battery disconnect cord in the
space provided in the battery doors. This will ensure a secure fit of the bezel to the unit.
Battery disconnect cord
Rack-mount configuration
Tower configuration
Battery disconnect cord
Display
