Appendix E. Atmel RZUSBSTICK Bill of materials
Qt Designator Description Manufacturer Part#
1 C18 Ceramic capacitor, SMD 0402, NP0, 50V,
±0.25pF 1.5p
2 C11, C12 Ceramic capacitor, SMD 0402, NP0, 50V,
±5% 12p
2 C22, C23 Ceramic capacitor, SMD 0402, NP0, 50V,
±5% 18p
2 C5, C6 Ceramic capacitor, SMD 0402, NP0, 50V,
±5% 22p
2 C2, C8 Ceramic capacitor, SMD 0402, X7R, 25V,
±10% 10n
1 C4 Ceramic capacitor, SMD 0402, X7R, 16V,
±10% Kemet C0402C104K4RACTU
12 C1,C10,C13,C16,
C17,C21,C24, C25, C26,
C3, C7, C9
Ceramic capacitor, SMD 0402, X5R, 6.3V,
±10% Kemet C0402C105K9PAC
2 R15, R16 Thick film resistor, SMD 0402, 1/16W, 1% 0R
2 R3, R8 Thick film resistor, SMD 0402, 1/16W, 1% 22R
5 R1,R10,R5,R6,R7 Thick film resistor, SMD 0402, 1/16W, 1% 470R
6 R12, R13, R14, R2, R4,
R9 Thick film resistor, SMD 0402, 1/16W, 1% 10k
1 L1 SMD RF inductor 0805. Murata BLM21AG102SN1D
1 Q1 General purpose NPN Philips BC847W
1 U5 Transient Suppressor TI SN65220YZBR
1 U1 AVR 8-bit RISC MCU with USB, QFN64
package ATMEL AT90USB1287-16MU
1 U2 2.4GHz ZigBee/802.15.4 tranceiver ATMEL AT86RF230-ZU
1 U3 2kb Serial (TWI) EEPROM, AT24C02B, ATMEL AT24C02B-TSU-T
1 U4 LDO 3.3V 150mA TI LP2985A-33DBV
1 XC1 16MHz uXtal GSX-323, Golledge GSX-323/111BF
16.0MHz
1 XC2 8.0MHz Xtal GSX-752 Golledge GSX-752B/551EF
8MHz
1 PCB1 RZUSBStick PCB ATMEL A08-0384
1 J2 USB type A plug, SMD SAMTEC USB-AM-S-F-B-SM1-R
1 D2 LED, Red Everlight EL17-21USRC
1 D3 LED, Green Everlight EL17-21SYGC
1 D4 LED, Yellow Everlight EL17-21UYC/A2
1 D1 LED, Blue Everlight EL17-21UBC
