Appendix B. Atmel AVRRAVEN Bill of materials
Qty Designator Description Manufacturer Part#
5 C205, C206, C207, C220,
C221 Ceramic capacitor, SMD 0402, NP0, 50V,
±0.25pF 1.2p
2 C201, C204 Ceramic capacitor, SMD 0402, NP0, 50V,
±5% 12p
3 C413, C414, C415 Ceramic capacitor, SMD 0402, NP0, 50V,
±10% 100p
1 C404 Ceramic capacitor, SMD 0402, X7R, 25V,
±10% 4.7n
14 C208, C301, C405, C407,
C408, C409, C410, C411,
C412, C416, C417, C420,
C421, C503 Ceramic capacitor, SMD 0402, X7R, 25V,
±10% 10n
2 C502, C504 Ceramic capacitor, SMD 0805, Y5V, 10V, -
20/+80% 4.7u
12 C211, C212, C213, C214,
C215, C303, C304, C305,
C306, C307, C418, C501 Ceramic capacitor, SMD 0402, X7R, 16V,
±10% Kemet C0402C104K4RACTU
10 C202, C203, C209, C210,
C302, C401, C402, C403,
C406, C505 Ceramic capacitor, SMD 0402, X5R, 6.3V,
±10% Kemet C0402C105K9PAC
4 R201, R208, R209, R415 Thick film resistor, SMD 0402, 1/16W, 1% 0R
7 R203, R306, R425, R427,
R428, R430, R434 Thick film resistor, SMD 0402, 1/16W, 1% 470R
5 R303, R401, R404, R405,
R417 Thick film resistor, SMD 0402, 1/16W, 1% 1k
1 R502 Thick film resistor, SMD 0402, 1/16W, 1% 1.5k
7 R304, R411, R412, R413,
R414, R432, R435 Thick film resistor, SMD 0402, 1/16W, 1% 3k
1 R410 Thick film resistor, SMD 0402, 1/16W, 1% 3.3k
17 R202, R206, R210, R211,
R212, R301, R302, R307,
R402, R406, R407, R408,
R421, R422, R423, R424,
R503 Thick film resistor, SMD 0402, 1/16W, 1% 10k
1 R305 Thick film resistor, SMD 0402, 1/16W, 1% 47k
10 R308, R309, R310, R409,
R416, R419, R426, R429,
R501, R504 Thick film resistor, SMD 0402, 1/16W, 1% 100k
3 R403, R418, R420 Thick film resistor, SMD 0402, 1/16W, 1% 470k
1 R431 NTC Thermistor 100kOhm Murata NCP18WF104J03RB
2 L401, L402 SMD RF inductor 0805 Murata BLM21PG300SN1D
2 L201, L501 SMD RF inductor 0805. Murata BLM21AG102SN1D
2 L202, L203 RF Inductor, 2.7nH, 0,17ohm, 300mA, 0402 Johanson
Technology
L-07C2N7SV6T
3 D401, D403, D408 Dual Schottky diode ST BAT54SWFILM
1 D501 Dual Schottky diode Philips 1PS70SB15
1 D404 Bidirectional Transient suppression diode,
600W ST SM6T12CA
