PREPARATION
P
R
EP
A
R
AT
IO
N
22
VESA WALL MOUNTING
Install your wall mount onto wooden studs perpendicular to the floor. When attaching to other building
materials, please contact a professional.
If installed on a ceiling or slanted wall, it may fall and result in severe personal injury.
We recommend that you use an LG brand wall mount when mounting the TV to a wall.
LG recommends that wall mounting be performed by a qualified professional installer.
Model
VESA (A * B)
A
B
Standard
Screw
Quantity
Wall Mounting Bracket
(sold separately)
47LX9500,
47LEX8
200 * 200 M6 4
LSW200B, LSW200BG,
LSW200BX, LSW200BXG
55LX9500,
55LEX8
400 * 400 M6 4
LSW400B, LSW400BG
50PK950 400 * 400 M6 4
AW-50PG60M AW-50PG60MS
60PK950 600 * 400 M8 4
AW-60PG60M AW-60PG60MS
