PC SETUP
EXTERNAL
EQ
UIPMENT
SETUP
28
EXTERNAL EQUIPMENT SETUP
This TV provides Plug and Play capability, meaning that the PC adjusts automatically to the TV's settings.
VGA (D-Sub 15 pin) Connection
Connect the VGA output of the PC to the R RG GB B IIN N
((PP C C)) jack on the TV.
Connect the PC audio output to the A AU UD DIIO O IIN N
((R RG GB B//D DV VII)) jack on the TV.
1. How to connect
2. How to use
■ Turn on the PC and the TV.
■ Select the R RG GB B--P PC C input source on the TV using the
II N N P P U U T T button on the remote control.
2
1
DVI to HDMI Connection
Connect the DVI output of the PC to the H HD DM MII//D DV VII
II N N 1 1 or H HD DM MII//D DV VII IIN N 2 2 jack on the TV.
Connect the PC audio output to the A AU UD DIIO O IIN N
((R RG GB B//D DV VII)) jack on the TV.
1. How to connect
2. How to use
■ Turn on the PC and the TV.
■ Select the H HD DM MII1 1 or H HD DM MII2 2 input source on the TV using
the IIN NP PU UT T button on the remote control.
2
1
RS-2
(CONTRO
Y P B P R
VIDEO AUDIO R L(MONO)
COMPONENT I
OPTICAL
DIGITAL
AUDIO OUT
/DVI IN
E
RJP
REMOTE
CONTROL IN
AV IN 1
1 2
RGB IN (PC)
AUDIO IN
(RGB/DVI)
AUDIO RGB OUTPUT
RS-232C IN
(CONTROL&SERVICE)
Y P B P R L
L
R
R VIDEO AUDIO R L(MONO)
COMPONENT IN
OPTICAL
DIGITAL
AUDIO OUT
EXTERNAL S
RJP
REMOTE
CONTROL IN
AV IN 1
DVI OUTPUT AUDIO
RGB IN (PC)
AUDIO IN
(RGB/DVI)
1
/DVI IN
2
1 2
1
2
