7. LED Description
The following table describes the LED’s located on the POE100 Series media
converter.
LED Colour Function
FX LNK/ACT Green
Lit when fibre connection has link
Blinks when fibre data is present
FX
FDX/COL
Amber
Lit when full-duplex mode is active
Off when half-duplex is active
Blinks when collision is present
TP LNK/ACT Green
Lit when Copper connection has link
Blinks when Copper data is present
TP 100 Green
Lit when Copper speed is 100Mbps
Off when Copper speed is 10Mbps
PWR Green Lit when +5V power is supplied
POE Green Lit when POE power is supplied
8. DC Jack and AC-DC Power Converter
The DC jacks central post is 2.5mm wide.
Fig. 10 DC+5V Input Jack and Dimension
DC Jack : 2.5mm
DC Input : +5V
