Chapter 2 – Asus SABERTOOTH 990FX User Manual
Page 40
2-22
Chapter 2: Hardware information
Chapter 2
2.
JMicron
®
JMB362 Serial ATA 3.0 Gb/s connectors (7-pin SATA3G_E1/E2 [black])
These connectors connect to Serial ATA 3.0 Gb/s hard disk drives and optical disc
drives via Serial ATA 3.0 Gb/s signal cables.
3.
Serial port connector (10-1 pin COM1)
This connector is for a serial (COM) port. Connect the serial port module cable to this
connector, then install the module to a slot opening at the back of the system chassis.
The COM module is purchased separately.
