ASUS M4A78-E 3-21
Chapter 3
Internal Graphics Mode [UMA�SidePort]
Configuration options: [Disable] [UMA] [SidePort] [UMA+SidePort]
UMA Frame Buffer Size [Auto]
Configuration options: [Auto] [32MB] [64MB] [128MB] [256MB] [512MB]
SidePort Clock Speed [DDR2-800MHz]
Configuration options: [DDR2-400MHz] [DDR2-533MHz] [DDR2-667MHz]
[DDR2-800MHz] [DDR2-1066MHz] [DDR2-1333MHz]
SidePort Voltage [Auto]
Configuration options: [Auto] [1.80V] [1.90V]
GFX Engine Clock Override [Disable]
Allows you to enable or disable the GFX Engine Clock Override support.
Configuration options: [Disable] [Enable]
GFX Engine Clock [500]
This item appears only when you enable the GFX Engine Clock Override item.Use
the <+> and <-> keys to change the value or type the desired value using the numeric
keypad. The values range from 150 to 1500.
Surround View [Disabled]
If you set the PCI Express device as the primary display and enable this item, you may use
the internal graphics as the secondary display.
Configuration options: [Disabled] [Enable]
PCI Express Configuration
PCI Express Configuration
Port #02 Features
Port #03 Features
Port #04 Features
Port #05 Features
Port #06 Features
Port #07 Features
NB-SB Port Features
BIOS SETUP UTILITY
Advanced
Port #02/03 Features
Gen2 High Speed Mode [Auto]
Configuration options: [Auto] [Disabled] [Software Initiated] [Advertised RC]
Link ASPM [Disabled]
Configuration options: [Disabled] [L0s] [L1] [L0s & L1]
Link Width [Auto]
Configuration options: [Auto] [x1 Mode.] [x2] [x4] [x8 Mode.] [x16]
