27
3. Remove the main door switch housing from the front panel (follow Main Door Switch Replacement
Procedure in Section X).
4. Disassemble main door hinge from the front panel by removing the four (4) nuts securing hinge to back side
of the front panel.
5. Position the new hinge, so that the part of the hinge that the main door is secured to, is towards the front
panel main door opening.
6. Install hinge studs through the front panel holes and secure in place with the four (4) nuts removed in Step
#4.
7. Reinstall the main door switch housing removed in Step #3.
8. Reverse Step #1 and Step #2.
