7
5. Pull up the two (2) metal fingers where the door switch harness is secured to the frame and right side panel
of the dryer.
6. Remove ALL nine (9) screws from the front panel. There are four (4) on the left side, four (4) on the right
side, and one (1) at the bottom of the panel behind the control door.
7. Gently remove the front panel assembly from dryer.
8 Reverse procedure to reinstall the front panel assembly.
9. Reestablish power to the dryer.
F. TO REMOVE/REPLACE LINT DRAWER SWITCH ASSEMBLY
1. Discontinue power to the dryer.
2. Remove the lint drawer and the control/lint door from the dryer (follow Lint Drawer and Control/Lint
Door Removal Procedures in Section A and Section B).
3. If the top basket (tumbler) is being serviced, remove the control box assembly (follow Control Box
Removal Procedure in Section D).
4. To remove the lint drawer switch box assembly, remove the two (2) screws inside the lint drawer area that
secure box to the side of the lint coop.
5. Disassemble the lint drawer box assembly from the dryer by disconnecting the two (2) harness connectors
from the box assembly.
6. Remove the two (2) Phillips head screws securing the cover to the switch mounting bracket.
7. Disassemble the switch from the box by removing the two (2) slotted head screws securing switch to the
bracket and disconnect the terminals from the switch.
8. Reverse procedure to reinstall the lint drawer switch assembly.
9. Reestablish power to the dryer.
G. TO REMOVE/REPLACE SENSOR BRACKET AND/OR ITS COMPONENTS
1. Discontinue power to the dryer.
2. Remove the lint drawer and the control/lint door from the dryer (follow Lint Drawer and Control/Lint
Door Removal Procedures in Section A and Section B).
3. Pull the front of the sensor bracket forward to remove it from the “S” clips. Pivot bracket downward and
assembly will separate from the sensor bracket holder.
