6
IMPORTANT: When removing the gas valve train assembly, be careful not to snag or damage the gas
valve train wiring disconnected in Step #6.
8. Reverse procedure to reinstall the gas valve train assembly.
NOTE: Be sure to open ALL gas shutoff valves closed prior to removing the gas valve train assembly.
9. Reestablish power to the dryer.
D. TO REMOVE CONTROL BOX
1. Discontinue power to the dryer.
2. Remove the lint drawer and the control door from the dryer (follow Lint Drawer and Control/Lint Door
Removal Procedures in Section A and Section B).
3. Remove screw located on the bottom right hand corner of the control panel.
4. Slide out the control box and hang the control box assembly on hinges located on the right side panel, and
disconnect the three (3) wiring harnesses (connectors) at the back of the control box.
5. The control box may now be taken out of the dryer completely. Depending on the service function to be
performed, the control box can be attached to the two (2) female hinges on the right side of the dryer
cabinet.
NOTE: If the control box is attached to the dryer cabinet, the three (3) wiring harnesses mentioned in
Step #4 DO NOT need to be disconnected.
6. Reverse procedure to reinstall the control box assembly.
7. Reestablish power to the dryer.
E. TO REMOVE FRONT PANEL
1. Discontinue power to the dryer.
2. Remove the control box assembly (follow Control Box Removal Procedure in Section D).
3. If the bottom front panel is being removed, the lower lint door must also be removed.
4. Disconnect the door switch connector from the lint drawer switch box assembly located under the basket
(tumbler) on the right side.
NOTE: There are two (2) harnesses that connect to lint drawer switch box. Locate and disconnect the
one that leads to the front panel.
