4.1.2 Jumpers and connectors
The motherboard of the PPC-L128T has a number of jumpers and connectors that
allow you to configure your system to suit your applications. The table below lists the
function of each of the board’s jumpers.
Table 4.1: Jumpers and Connector functions
CN1 LVDS connector
CN3 Inverter power connector
CN4 CF Slot ,TYPEII
CN5 SATA HDD signal connector (2.5" HDD)
CN6 SATA HDD power connector (2.5" HDD)
CN7 DDR2 SO-DIMM
CN8 MINI PCIe slot
CN9 5 Wires T/S connector
CN11 SATA ODD signal connector
CN12 SATA ODD power connector
CN16 PCIe (x1) slot
CN18 PCI bus expansion slot
CN19 Internal USB connector
CN23 Internal Speaker connector
CN33 Internal power connector
CN40 LCD light sensor connector
CN41 Front panel connector
PCN1 Battery connector
CN13 Clear CMOS connector
CN14 AT/ATX selection connector
CN20 COM1/2 Pin9 function selection
CN21 COM3 Pin9 function selection
