American DJ DJ Scan/RG - Manual (Page 4)

12).
7.
Please follow chart on page 12 for all slave dipswitch settings. Note only one fixture may use the master units dip switch settings (see Page 12).
8.
After all the units settings have been set and are plugged in, adjust the sensitivity knob on the bottom of the master unit to make them react to sound.
9.
To run a synchronized light show set all the dip switch on all the fixture
to
the
‘off’
position.
All
fixtures
will
now
run
in
the
same
exact pattern.
10.
You can also use the optional MINI/C Remote Control. If you want to use the optional remote control, connect the MINI/C controller to the first fixture in the line (master).
Note: The remote control only operates in Stand-Alone and Master/ Slave modes. If the remote is connected in DMX mode it will not function.
If
the
units
do
not
receive
an
active
DMX
signal,
the
units will automatically react to sound in the Master/Slave mode. DMX Mode: This fixture will react with DMX
operation. For best results use only
one
motor
function
for
each
scene
(or
step),
when
programming
scenes into a DMX controller
.
This will give you faster mirror and faster
gobo/color changes. For Example:
A. With DMX controller move the mirror up then program the step. B. Move the mirror down then program that step. C. Change the gobo/color wheel then program that step. D. Continue this pattern to achieve best results.
1.
Operating
through
a
DMX
controller
gives
the
user
freedom
to
create his/her own programs tailored to their own individual needs. This function also allows you to use your fixtures as spots.
2.
This operation will allow you to control each individual fixtures traits with a standard DMX 512 controller such as the
American DJ Show
Designer™ or the
American DJ
® DMX Operator
.™
3.
The DJ Scan/RG™ uses four DMX channels to operate; Channel 1 is Pan, channel 2 is
T
ilt, channel 3 is Color
, and channel 4 Gobos.
4.
T
o
run your fixture in DMX mode, plug in the fixture via the XLR
connections
to
any
standard
DM
X controller
. - Follow the set-up
specifications that come with the controller
.
DJ Scan/RG™
Operating Instructions
DJ Scan/RG™
Operating Instructions
©
American DJ Supply
®
- www
.americandj.com - DJ Scan/RG™ Instruction Manual Page 8
©
American DJ Supply
®
- www
.americandj.com - DJ Scan/RG™ Instruction Manual Page 7
Operating Modes:
You can use the DJ Scan/RG
™
in three ways:
•
Stand alone mode -
The unit will react to sound, chasing through
the
several
built
in
programs.
You
can
also
use
the
optional
DJ
Scan MINI/C Remote Control to blackout the units. • Master/Slave mode -
You can daisy chain up to 4 units together to
get
a
synchronized
light
show
that
will
react
to
sound
chasing
through several built in programs. •
DMX
control
mode
-
This
function
will
allow
you
to
control
each
individual fixtures traits with a standard DMX 512 controller such as
the American DJ Show Designer.
™
For best results use fog or special ef
fects smoke to enhance the beams
projections.
The DJ Scan/RG™ comes with a protective transportation
cover
. Be sure to remove it before attempting any operation!
Stand Alone Mode: 1.
To
operate
as
a
stand
alone
unit,
via
its
internal
chases
and
microphone, turn all dip switches of
f (see Diagram 1).
2.
Adjust
the
sensitivity
knob
on
the
bottom
of
the
unit
so
the
unit
will react to sound.
3.
The DJ Scan/RG™ will now react to the bass sound of music via
the
internal microphone.
Master-Slave Operation: 1.
This function will allow you to link up to 16 units together to run on the master unit’s 2 channel internal programs.
2.
In Master-Slave operation one unit will act as the controlling unit and the others will react to the controlling units programs. Any unit can act as a Master or as a Slave.
3.
Daisy
chain
your
units
via
the
XLR
connector
on
the
bottom
of the units.
4.
Use standard XLR microphone cables to link your units together. Remember
that
the
Male
XLR
connector
is
the
input
and
the
Female XLR connector is the output.
5.
The first unit in the chain (master) will use the female XLR connec- tor only -
The last unit in the chain will use the male XLR connector
only.
6.
T
urn all the master units dip switches to the of
f position (see Page
