DJ Scan/RG™
Quick Star
t
The
DJ
Scan/RG™
features
a
bright
150
watt/500
hour
lamp
life
halogen bulb with a separate gobo and color wheel.
The color wheel
features seven brilliant colors plus white and the gobo wheel features 6 gobos plus a large and small spot.
This fixture incorporates the use
of high quality stepper motors for a more accurate mirror movement. Mirror
movement
allows
for
a
full
90
degree
tilt
(vertical)
and
a
45
degree
pan
(horizontal).
An
internal
built
in
microphone
allows
the
fixtures to run in Stand
Alone mode so there is no need for an external
controller
.
The DJ Scan/RG™ may also be set-up to run in a Master-
Slave mode when used in multiples, up to four units. When used in the Master-Slave mode, the unit will chase to several internal programs. The DJ Scan/RG™ can also be controlled via a standard DMX control- ler
such
as
the
American
DJ
® Show
Designer
,™
or
the
American
DJ
® DMX
Operator
,™
giving
the
user
independent
control
over
the
gobo and color wheel as well as the mirrors pan and tilt movements. Note:
The built in programs in the DJ Scan/RG™ are so good you may
never need a DMX controller
.
•
ZB-JCR/H5 15V/150W
, 500 Hour Lamp.
•
DMX-512 Compatible.
•
Stepper motors for smooth movements.
•
7 colors plus white.
•
7 Gobos plus spot.
•
4 Rotating Gobos, 4 Fixed Gobos.
•
4 Replaceable Gobos (26mm diameter - 22mm viewable)
•
Master/Slave Operation
•
Sound Active.
•
Optional MINI/C controller
, for blackout control.
DJ Scan/RG™
Featur
es
Master/Slave Quick Start Stand
Alone Mode
Connect
up
to
four
units
together
via
XLR
cables.
The
master
unit
will
run
the
slaves
to
the
masters
built
in
programs
and
internal
microphone. Plug in all units. When the DJ Scan/RG™ is first turned on, it will run through an internal self test where it resets all motors to their zero position.
After the self test the units will react to sound, and
chase to the several built in programs.
•
Do not spill water or other liquids into or on to your unit.
•
Be sure that the local power outlet match that of the required voltage for your unit.
•
Do not attempt to operate this unit if the power cord has been frayed or broken. Please route your power cord out of the way of foot traffi
c.
•
Do not attempt to remove or break of
f the ground prong from
the electrical cord.
This prong is used to reduce the risk of electrical
shock and fi
re in case of an internal short.
•
Disconnect
from main power before making any type of connection.
•
Do not remove the top cover under any conditions.
There are no
user serviceable parts inside.
•
Never plug this unit in to a dimmer pack
•
Always be sure to mount this unit in an area that will allow proper ventilation.
Allow about 6” (15cm) between this device and a wall.
•
Do not attempt to operate this
unit,
if
it
becomes damaged in any
way.
•
Never operate this unit when it’
s cover is removed.
•
To
reduce the risk of electrical shock or fi
re, do not expose this unit
rain or moisture
•
This unit is intended for indoor use only
, use of this product outdoors
voids all warranties.
•
During long periods of non-use, disconnect the unit’
s main power
.
•
Always mount this unit in safe and stable matter
.
•
Power Cord Protection - Power cords should be routed so they are not likely to be walked on or pinched by items placed upon or against them,
paying
particular
attention
to
cords
at
plugs,
convenience
receptacles, and the point where they exit from the unit.
• Cleaning -The fixture should be cleaned only as recommended by
the manufacturer
.
•
Heat
-The
unit
should
be
situated
away
from
heat
sources
such
as
radiators,
heat
registers,
stoves,
or
other
appliances
(including
amplifiers) that produce heat.
•
The fixture should be serviced by qualified service personnel when:
A.
The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the appliance.
C.
The appliance has been exposed to rain or water
.
D.
The
fixture
does
not
appear
to
operate
normally
or
exhibits
a
marked change in performance.
DJ Scan/RG™
Safety Pr
ecautions
