2.15 GPIO connector (GPIO1)
The DVMB-554E provides a GPIO interface, GPIO1, which is a 20 pin
connector. Advantech provides SDK for this GPIO and have 7 pins for input
and 8 pins for output. Please refer to pin assignments for GPIO1
connector as below.
GPIO connector (GPIO1)
Pin
signal
pin
signal
pin
signal
pin
signal
1
+5V
6
Input
11
Output 16
Input
2
+5V
7
Output 12
Input
17
Output
3
Output 8
Input
13
Output 18
GND
4
Input
9
Output 14
Input
19
GND
5
Output 10
Input
15
Output 20
GND
