10
g
Using the measurement on the quilting foot as
a guide, sew around the motif.
a 6.4 mm (approx. 1/4 inch)
Finished project
h
Press to cancel the free-motion sewing
mode.
Measurements on the Bobbin Cover
The measurements on the bobbin cover are references
for patterns with a middle (center) needle position. The
measurements on the needle plate and the needle plate
cover are references for stitches with a left needle
position.
a For stitches with a middle (center) needle position
b For stitches with a left needle position
c Left needle position on the needle plate
d Left needle position on the needle plate
e Middle (center) needle position on the bobbin cover
f Left needle position on the needle plate cover
b
a b
c
d
e
f
