American Power Conversion 8000 VA - Manual (Page 3)

1
Introduction
The APC Smart-UPS® RT is a high-performance, uninterruptible power supply (UPS) that provides
protection for electronic equipment from utility power blackouts, brownouts, sags and surges. The
UPS filters small utility line fluctuations and isolates electronic equipment from large disturbances
by internally disconnecting from utility line power. The UPS provides continuous power from the
internal battery until utility power returns to safe levels or the battery is fully discharged.
I
NSTALLATION
Read the Safety Instruction sheet before installing the UPS.
Unpacking
Inspect the UPS upon receipt. Notify the carrier
and dealer if there is damage.
The packaging is recyclable; save it for reuse or
dispose of it properly.
Check the package contents.
ƒ
UPS
ƒ Front bezel
ƒ Literature kit containing:
ƒ Software CD
ƒ Smart-UPS User Manuals CD
ƒ Serial cable
ƒ Six output power cords
ƒ Two battery cable assemblies
ƒ Two ground wires
ƒ Product documentation, warranty
information, and safety information
ƒ Network Management Card
documentation
Specifications
T EMPERATURE
O PERATING
S TORAGE
32 ° to 104° F (0° to 40° C)
5 ° to 113° F (-15 to 45 ° C) charge UPS battery every six months
M AXIMUM
E LEVATION
O PERATING
S TORAGE
10,000 ft (3,000 m)
50,000 ft (15,000 m)
H UMIDITY 0% to 95% relative humidity, non-condensing
This unit is intended for
indoor use only. Select a
location sturdy enough to
handle the weight.
Do not operate the UPS where
there is excessive dust or the
temperature and humidity are
outside the specified limits.
Ensure the air vents on the
front and rear of the UPS
are not blocked.
W EIGHT
UPS
UPS
WITH
P ACKAGING
244 lbs (111 kg)
284 lbs (129 kg)
