8
Use the “s“UP or “t“DOWN buttons to scroll through the MAIN MENU or OPTIONS. Press “SEND” to select displayed
screen choice. NOTE: Rotate the selector off menu at any time to EXIT. Selections will NOT be saved unless you press “SEND”
PRESS “s“UP to scroll through menu items in this order.
press “s“ press “s“
MAIN MENU SUB MENU OPTIONS Notes
SETUP SET TIME Use to set current time.
SET DATE Use to set current date.
C < - - -> F ˚F or ˚C Use to select temperature scale.
LANGUAGE ENGLISH Use to select language.
FRENCH
SPANISH
EXIT Return to main menu.
GAS ZERO RESET GAS ZERO Press “SEND” to start.
(EagleX ONLY) Automatically returns to main menu.
PRESSURE SMOOTH ON/OFF Use to change screen update rate.
RESOLVE HIGH Use to select display resolution.
LOW
PS UNITS Use to select desired unit of measure. Choose beetween:
In H2O inches H2O (water gauge)
mbar millibar
mmH2O millimeters of H2O
Pa Pascals
kPa Kilopascals
PSI Pounds per square inch
mmHg Millimeters of mercury
hPa Hecto pascals
EXIT Return to main menu.
REPORT COMB’N VIEW When viewing reports:
PRESSURE DEL ALL -Press “s“UP or “t“DOWN to select report #.
EXCH -Press and hold “s“UP or “t“DOWN to change the displayed
TEMP lines in VIEW.
ROOM CO -Press SEND to print current viewed report.
-Press and hold SEND to exit view.
EXIT Return to Sub Menu.
EXIT Return to main menu.
SCREEN CONTRAST 00~20 Use to change screen contrast.
AUX LINE 1 -Select parameter displayed for each line.
LINE 2 -Press “s“UP to choose between:
LINE 3 ∆T Temp differential TIME (shows time)
LINE 4 CO Carbon Monoxide DATE (shows date)
P Pressure Losses
X Excess Air R CO/CO2 Ratio
Efn Efficiency CO2 Carbon Dioxide
NO NO O2 Oxygen
COa CO Air Free TI Inlet Temp (T1)
BAT Battery Level TF Flue Temp (T2)
D Draft
EXIT Return to Sub Menu.
HEADER HEADER1 Customize header information
HEADER2 Screen shows (*OUR COMPANY NAME &_ _ _ _)
-Press UP or DOWN to scroll through letters and symbols to
choose, press ENTER.
EXIT Return to Sub Menu.
EXIT Return to main menu.
SERVICE Used by technicians to calibrate combustion gas sensors.
