EAGLE & EAGLE X O
vErviEw
Infrared Printer Port Worklight
On/Off Button
Navigation “s“UP
and Backlight
Navigation “t“DOWN
and PUMP
SEND/ENTER
to Select and Print
Rotary Test Selector Dial
Battery Compartments
in back under boot
AC Power/Charge
Indicator Light
4 Line Backlit Display
Display Line Lights
Particle Filter
Inside Water Trap
Water Trap
Protective Rubber Boot
w/ built-in Magnets
Flue Probe Temperature Plug
(Plugs into T1)
Narrow Pin MUST be on the
Right hand side.
Flue Probe
Gas Inlet Plug
Temperature
Connections
Flue Probe Temp: T1
Inlet Temp: T2
Pressure Connections
• Single Input (Draft): P1
• Differential Input Testing
(Pressure drop test) P2
Flue Gas
Inlet Connection
Water Trap
Drain
Battery Charge
AC Adapter
