5.2 Setting a data length
5.3 Setting a stop bit length
5.4 Setting a parity
While in the "Set a communications parameter" screen on the preceding page, operate the ▲ and
▼ keys to make the settings.
The initial value is [
].
Stop bit 1
Stop bit 2
No parity
Odd parity
Even parity
Data length, 7 bits
Data length, 8 bits
* The ASCII mode settings come only in three types: , , and .
The RTU mode settings come only in three types: , , and .
5.5 Setting a communications speed
While in the "Set a communications speed" screen on the preceding page, operate the ▲ and ▼
keys to make the settings.
The initial value is [
].
１２００ｂｐｓ
２４００ｂｐｓ
４８００ｂｐｓ
９６００ｂｐｓ
１９２００ｂｐｓ
