2
a b c d e f
10 9 8 11 12
Fig 1b - Internal
intercom
(Rear view and wall
mounting plate)
8. Volume control
9. Brightness control
10. Contrast control
(colour control DCC2)
11. Mains adaptor low
voltage socket
12. Wall mounting plate
Fig 1c - External Intercom and Wall Box
a. Camera and LED lighting assembly
b. Integral speaker
c. Name plate
d. Call button
e. Integral microphone
f. Wall box
Knock-outs for
cable entry
