Continue to adjust until the unit operates as desire d .
Masking the Sensor Lens
To restrict the sensor coverage, preventing detection in
unwanted areas, mask the sensor lens using the masks
p rovided in the accessory pack (see diagram D). For
your information, the top section of the lens covers long
range detection, the bottom covers short range. Similarly
the left and right lens sections cover the left and right
detection areas re s p e c t i v e l y.
180 degree rotation of
sensor head ensures
accurate detection control
Installation aid.
clip main body
onto wall plate
for easier wiring
E
F
H
Wall mount Ceiling or eave
mount
Extra view shows
details of clip
arrangement
1. Align top
edge and click
Fully tighten
sensor fixing
screw
Wiring box
fixing screw
2. Rotate
sensor body
down and
“click”
lower edge
into place
G
I
