6
Operation and testing
Walk Test Procedure
The detector will adjust vertically through 180 degre e s
Adjust the detector to point at the desired elevation.
Angling down will limit forward looking range.
Set the two adjustment controls on the underside of the
unit (diagram C) to the following positions:
TIME - Fully anti-clockwise
DUSK - Fully clockwise
The unit will now operate during daytime as well as at
night, illuminating the lamp for approx. 5 seconds each
time detection occurs. This allows testing to be carried
out to establish the best position for the sensor. The lamp
will immediately illuminate as the unit goes through its
"warm-up" period. After approximately 1 minute the
lamp will extinguish. Try to remain outside the detection
a rea during the warm-up period.
Walk across the detection area approx 5 metres from the
unit. As you cross a detection "zone" the lamp will
illuminate. Now stand still until the lamp extinguishes
(this should take approx. 5 seconds).
Start moving again. As you cross each "zone" the lamp
will illuminate.
Manual Override Mode
The light can be switched on for longer time periods by
use of the Manual Override Mode. This can be
activated at night by using the internal wall switch or
circuit breaker.
Switch the isolation switch (off/on, off/on) within 2
seconds. The unit will now illuminate continuously
until dawn or until it is switched back into Auto Mode.
To switch the unit back into Auto Mode, switch the
isolation switch off/on once within 1 second. The unit
will return to Auto Mode.
