Timeguard LEDX30FLB User Manual
Led uncontrolled floodlight, Helpline, Warning

5
6
67.058.501 (Iss.2)
LED UNCONTROLLED
FLOODLIGHT
In
st
a
lla
tio
n
&
O
p
e
rati
n
g I
n
stru
ct
ion
s
LEDX10/20/30FLB.1_Instructs_147x105.indd -R3 5,7
27-01-2014 9.40pm
Prepared by: Sally
LEDX10FL, LEDX20FL, LEDX30FL
Model: LEDX30FLB
Model: LEDX30FLWH
Timeguard Limited.
Victory Park, 400 Edgware Road,
London NW2 6ND
Sales Offi ce: 020 8452 1112
or email csc @ timeguard.com
For a product brochure please contact:
or email helpline @ timeguard.com
HELPLINE
020 8450 0515
Lamp Adjustment
Tilt downward 60º
WARNING
Model: LEDX10FLB
Model: LEDX10FLWH
Model: LEDX20FLB
Model: LEDX20FLWH
Tilt upward 45º
The lamp can be tilted upward 45º and
tilted downward 60º.
-20
+40
10
20
30
40
50
60
Energy Efficiency
Class A+
Energy Usage
9kWh/1000h: 9W typ
Power Supply
230V AC
~ 50Hz
Lumen Output initial
Black: 685 Im typ, White: 750 lm typ
Lamp Beam Angle
110 x 100 degrees
The lamps are not replaceable in this product
Environmental Protection IP55 (suitable for indoor and outdoor use)
EC Directives Conforms to current EC Directives
Energy Efficiency
Class A+
Energy Usage
16kWh/1000h:15.6W typ
Power Supply
230V AC
~ 50Hz
Lumen Output initial
Black: 1260 Im typ, White: 1325 Im typ
Lamp Beam Angle
110 x 100 degrees
The lamps are not replaceable in this product
Environmental Protection IP55 (suitable for indoor and outdoor use)
EC Directives Conforms to current EC Directives
3 Year Guarantee
In the unlikely event of this product becoming faulty due
to defective material or manufacture within 3 years of the
date of purchase, please return it to your supplier in the
first year with proof of purchase and it will be replaced free
of charge. For years 2 and 3 or any difficulty in the first year telephone
the helpline on 020 8450 0515.
020 8450 0515
If you experience problems refer to Troubleshooting Guide.
If problems still exist, do not immediately return the unit to store.
Telephone the Timeguard Customer Helpline
Qualified Customer Support Co-ordinators will be on-line to assist
in resolving your query.
This product will get warm when
in normal use. Can be installed
on surfaces of normal flammability
e.g. wood, plasterboard,
brickwork and other masonry.
Do not install on flammable
surfaces such as plastics.
Note:
A proof of purchase is required in all cases. For all eligible replacements
(where agreed by Timeguard) the customer is responsible for all
shipping/postage charges outside of the UK. All shipping costs are to be
paid in advance before a replacement is sent.
LEDX30FL Technical specifications:
Power Factor > 0.95
Colour Temperature
5000 - 5600k
Colour Rendering
> 70
LEDX10FL / LEDX20FL / LEDX30FL Technical specifications:
Energy Efficiency
Class A+
Energy Usage Lamp On
27kWh/1000h: 27W typ
Power Supply
230V AC
~ 50Hz
Lumen Output initial
Black: 2115 Im typ, White: 2310 lm typ
Lamp Beam Angle
110 x 100 degrees
The lamps are not replaceable in this product
Environmental Protection IP55 (suitable for indoor and outdoor use)
EC Directives Conforms to current EC Directives
LEDX20FL Technical specifications:
LEDX10FL Technical specifications:
