red LED flashes
on the sensor
Allocate sensors
The SENSORS are allocated in the menu
under OPTIONS.
Press MENU (see picture).
Connection options:
1 LUNA + 4 light sensors
10 LUNA + 1 light sensor
∑ max. 16 devices (LUNA + light sensors)
Presetting: all connected sensors are
active for all channels. The sensor that
sends the lowest lux value is active.
CHANNEL
C1
1 SENSOR
RECOGNISED
1 ACTIVE
SENSOR
SENSOR 1
READING
SENSOR 1
ACTIVE DEACTI-
VATE
NO
SENSOR
OPTIONS
SENSORS
OPERATING
HOURS METER
EXTERNAL
OUTPUT
LCD ILLUMI-
NATION
LANGUAGE
PIN
FACTORY
SETTING
INFO
END
