4-4 Basic Setting of the Filling Level in the Conveyor Hopper
The filling level in the conveyor hopper is mainly determined by the level sensor.
Figure 4.1: Conveyor Hopper
Function and features:
• Capacitive level switch for monitoring and dry bulk material, preferably plastic granulates.
• Automatic adjustment to the medium to be detected by means of programming pushbutton.
• The sensing face is rated for temperatures up to 110°C and can be mounted in direct contact
with the sight glass (without air gap).
Mounting:
Mount the level switch as shown:
Electrical Connection:
Disconnect the installation from power. Connect the unit
(see type label).
Operation:
Adjust the sensor. To do so, press the programming
pushbutton with a blunt object.
