A p p e n d i x 2
Appendix 2 Technical Specifications
AC PASS-THROUGH SPECIFICATIONS
DC INPUT AMPERAGE
TruePower Combi
1000 QS
1500 QS
2500 QS
2000 PS
Input Voltage
120Vac
110/230VAC
Low Voltage Disconnect
85Vac
± 4%
85/184Vac
± 4%
Low Voltage Reconnect
95Vac
± 4%
95/194Vac
± 4%
High Voltage Disconnect
132Vac
± 4%
136/253Vac
± 4%
High Voltage Reconnect
127Vac
± 4%
132/243Vac
± 4%
Nominal Input Frequency
50Hz / 60Hz (Auto Detection)
Transfer Switch Rating
30A
Pass Through Without Battery
Yes
Maximum Pass Through Overload
30A
(110 VAC 60 Hz.) 12 Volt QS Models
01012 True
Power
Combi - 12V 40A/1000W Combination Charger/Inverter - 110Vac 60hz
10.5 - 15Vdc
Up to 100A
01512 True
Power
Combi - 12V 40A/1500W Combination Charger/Inverter - 110Vac 60hz
10.5 - 15Vdc
Up to 150A
02412 True
Power
Combi - 12V 40A/2500W Combination Charger/Inverter - 110Vac 60hz
10.5 - 15Vdc
Up to 250A
(110 VAC 60 Hz.) 24 Volt QS Models
01524 True
Power
Combi - 24V 20A/1500W Combination Charger/Inverter - 110Vac 60hz
21.5 - 29.5Vdc
Up to 75A
02424 True
Power
Combi - 12V 40A/1500W Combination Charger/Inverter - 110Vac 60hz
21.5 - 29.5Vdc
Up to 125A
(230 VAC 50 Hz.) 12 Volt QS Models
01513 True
Power
Combi - 12V 40A/1500W Combination Charger/Inverter - 230Vac 50hz
10.5 - 15Vdc
Up to 150A
02423
True Power Combi - 12V 50A/2500W Combination Charger/Inverter - 230Vac 50hz
10.5 - 15Vdc
Up to 250A
(230 VAC 50 Hz.) 24 Volt QS Models
01525 True
Power
Combi - 24V 20A/1500W Combination Charger/Inverter - 230Vac 50hz
21.5 - 29.5Vdc
Up to 75A
02425
True Power Combi - 24V 25A/2500W Combination Charger/Inverter - 230Vac 50hz
21.5 - 29.5Vdc
Up to 125A
TruePower Combi - Combination Charger / Inverter with Automatic Crossover
DC Voltage
(range)
DC Amps
(max continuous)
(110 VAC 60 Hz.) PS Models
02012 True
Power
Combi
- 12V 70A/2000W Combination Charger/Inverter - 110Vac 60hz
10.5 - 15Vdc
Up to 200A
02024
True Power Combi - 24V 35A/2000W Combination Charger/Inverter - 230Vac 50hz
21.5 - 29.5Vdc
Up to 100A
(230 VAC 50 Hz.) PS Models
02013
True Power Combi - 12V 70A/1500W Combination Charger/Inverter - 230Vac 50hz
10.5 - 15Vdc
Up to 200A
02025
True Power Combi - 24V 35A/2000W Combination Charger/Inverter - 230Vac 50hz
21.5 - 29.5Vdc
Up to 100A
Pure Sine Wave Combination Charger / Inverter with Automatic Crossover
DC Voltage
(range)
DC Amps
(max continuous)
A p p e n d i x 2
33
Appendix 2 Technical Specifications
TruePower Combi
1000 QS
1500 QS
2500 QS
2000 PS
Power
1000W
1500W
2400W
2000W
Continuous Power
1000W
1500W
2400W
2000W
Surge Power
3000W
4500W
7200W
6000W
Output Waveform
Modified Sine Wave Sine Wave
AC Output Voltage
110
110 /230
110/230
110/230
DC Input Voltage
12
12 /24
12/24
12/24
Efficiency
>80%
Cooling Fan
Yes
Short Circuit Protection
Yes
Soft Start
Yes
High Voltage Protection
Yes
Reverse Polarity Protection
Yes
Capable of Starting Electric Motor
1/2 hp
1/2 hp
1 hp
1 1/2 hp
Low Battery Alarm
10.5Vdc
±'b1 0.3Vdc for 12V battery
21Vdc
±'b1 0.6Vdc for 24V battery
Low DC Input Shut Down
10.Vdc
±'b1 0.3Vdc for 12V battery
20Vdc
±'b1 0.6Vdc for 24V battery
High DC Input Alarm & Fault
16Vdc
±'b1 0.3Vdc for 12V battery
32Vdc
±'b1 0.6Vdc for 24V battery
High DC Input Recovery
15.5Vdc
±'b1 0.3Vdc for 12V battery
31Vdc
±'b1 0.6Vdc for 24V battery
Power Saver
Load <20W (enabled on “stand by” setting of Remote Panel)
INVERTER SPECIFICATIONS
CHARGER SPECIFICATIONS
TruePower Combi
1000 QS
1500 QS
2500 QS
2000 PS
Input Voltage
120V
110/230V
Nominal Charge
40A-12Vdc 40A-12Vdc 50A-12Vdc 70A-12Vdc
20A-24Vdc 25A-24Vdc 35A-24Vdc
Charge Current Regulation
± 5Adc
Battery Initial Voltage
0-15.7Vdc
0-16Vdc for 12V
(can operate w/ 0Vdc battery)
0-32Vdc for 24V
(can operate w/
0Vdc battery)
Charger Breaker Size
16A
20A
20A
30A
