Warning Typical Wiring Configurations
CAUTION:
- HOT SURFACES - TO REDUCE THE RISK OF BURNS, DO NOT TOUCH.
- CHARGE ONLY USER SELECTABLE TYPE BATTERIES (FLOODED, AGM, GEL OR CALCIUM) OTHER TYPES OF
BATTERIES MAY BURST CAUSING PERSONAL INJURY AND DAMAGE
- RISK OF ELECTRIC SHOCK. NO USER SERVICEABLE PARTS. RETURN TO MANUFACTURER FOR SERVICING
- THIS CHARGER IS MEANT FOR CONTINUOUS DUTY
- IGNITION PROTECTED
- FOR MARINE USE
ATTENTION :
- SURFACES CHAUDE-NE PAS TOUCHER, RISQUES DE BRULURES
- UTILISER POUR ATTENTION: CHARGER UNIQUEMENT LES BATTERIES DU TYPE (PLOMB/ACIDE OU PLOMB/GEL/
AGM ET BATTERIE AU CALCIUM). D’AUTRES TYPES DE BATTERIES POURRAIENT ÉCLATER ET CAUSER DES
BLESSURES OU DOMMAGES
- RISQUE DE CHOCS ELECTRIQUE-RETOURNER AU FABRIQUANT POUR SERVICE.
- CE CHARGEUR EST FABRIQUE POUR LE DEVOIR CONTINU
- PROTÉGÉ CONTRE L’EXPLOSION
- POUR UTILIZATION MARINE
WARNING: LOW VOLTAGE / ATTENTION : BASSE TENSION
ELECTRICAL BURN AND SPARK HAZARD. BEFORE OPENING DISCONNECT CHARGER CONNECTIONS AT
BATTERY(S).(DANGER DE BRULURES ELECTRIQUE ET ETINCELLES). AVANT D'OUVRIR LA BOITE DECONNECTER
LES CONNECTIONS ENTRE CHARGEUR ET BATTERIE.
WARNING: HIGH VOLTAGE / ATTENTION : HAUTE TENSION
AVOID SERIOUS INJURY OR DEATH FROM ELECTRICAL SHOCK. BEFORE OPENING TURN OFF AC SUPPLY POWER.
CHOC ELECTRIQUES PEUVENT PROVOQUER LA MORT OU DE SERIEUSE BLESSURES. AVANT D'OUVRIR LA BOITE,
COUPER LE COURANT.
WARNING / AVERTISSEMENT :
DO NOT EXPOSE TO RAIN OR SPRAY / NE PAS EXPOSER AUX INTEMPÉRIES
Before connecting to batteries or AC power, read all instructions and cautionary markings
on the battery charger and batteries. Do not discard this manual, save it for future reference.
EXTERNAL CONNECTIONS TO CHARGER SHALL COMPLY WITH THE UNITED STATES COAST GUARD
ELECTRICAL REGULATIONS (33CFR183, SUB PART 1).
1. SAVE THESE INSTRUCTIONS - This manual contains important safety, operating and installation
instructions for the ProNauticP Series Battery Charger. Do not discard this manual, save it for
future reference.
2. Do not expose charger to rain or snow.
3. Use of attachments not recommended or sold by Professional Mariner, LLC will void warranty
and may result in a risk of fire, electrical shock or personal injury.
4. Do not operate the charger if it has received a sharp blow, direct hit of force, been dropped or
otherwise damaged in any way.
5. Do not disassemble the battery charger. If service or repair is required please contact customer
service at 1-800-824-0524. Incorrect reassembly may result in a risk of electric shock or fire.
6. To reduce the risk of electrical shock, remove 120 volt or 240 volt AC shore power. Also remove
DC battery connections prior to any maintenance or cleaning. Turning off controls will not reduce
this risk.
WARNING: AVOID SERIOUS INJURY OR DEATH FROM FIRE, EXPLOSION OR ELECTRICAL SHOCK
- Make connection in an open atmosphere free of explosive fumes.
- Make connection in a secure manner that will avoid contact with water.
5 26
ProNautic 12
•
60 P
Power Factor Corrected & Global AC Input
DC Fuse DC Fuse
Main Grounding Bus
to Engine Negative
DC Charger Output
Case Ground
1 Size Smaller than the +
L
N
G
AC Input
12V Battery/Battery Bank
Typical 2 Bank12 Volt DC Common Ground Installation:
Battery Profiles Charger Conditions
Charger Mode Auto Maintain Conditioning Charging
AC Power
Auto Temp Control
Active PFC
Amps Volts
SYSTEM DC OUTPUT LEVELS
Variable Speed Cooling
Self Test
Fault
OK
Standby AUTO CONSERVATION MODES
100% 0%
Battery Health Program
Equalization
Charger Output
SETUP
ENTER
WARNING: HIGH VOLTAGE
ATTENTION : HAUTE TENSION WARNING: LOW VOLTAGE
ATTENTION : BASSE TENSION
P reset-1 P reset-2
Flooded
Sealed
AGM
GEL
LiFePO4-Lithium
Calcium/Custom
Reverse Polarity
DC Volts Low
DC Volts High
Charger High Temp
Check Fan
Digital ProMar Performance Charging
1 2 3
AVOID SERIOUS INJURY OR DEATH FROM ELECTRICAL SHOCK. BEFORE OPENING
TURN OFF AC SUPPLY POWER. DO NOT EXPOSE TO RAIN OR SPRAY.
CHOC ELECTRIQUES PEUVENT PROVOQUER LA MORT OU DE SERIEUSE BLESSURES.
AVANT D'OUVRIR LA BOITE, COUPER LE COURANT. NE PAS EXPOSER AUX INTEMPÉRIES. ELECTRICAL BURN AND SPARK HAZARD. BEFORE OPENING
DISCONNECT CHARGER CONNECTIONS AT BATTERIES.
(DANGER DE BRULURES ELECTRIQUE ET ETINCELLES). AVANT D'OUVRIR LA
BOITE DECONNECTER LES CONNECTIONS ENTRE CHARGEUR ET BATTERIE. DISPLAY WAKE UP: Press any key; SELF TEST: Hold all keys 5 seconds
