86313050 LEGEND GT
Heat Exchanger
REF
PART NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES
1
86270330
17
FLATWASHER, 1/4
2
86175920
1
BUSH, 3/8 X 1/8 BR
3
86180220
5
ELL, 3/8 BR
4
86194170
1
TEE, 3/8, BRASS, 2203P-6
5
86181330
1
FTTG, BRB 3/8PX1/2H BR
6
86180410
1
ELL, 3/8P X 1/2T BR
7
86177700
3
CONN, 3/8P X 1/2T BR
8
86181400
1
FTTG, BRB 3/8P x 5/8H BR
9
86192490
1
SENDER, TEMP 140-320 DEG
10
86182190
6
GROM, 1/2 ID X 1-1/8 OD
11
86006740
6
SCR, 3/8-16 X 1.00 HHCS GR5
12
86274750
17
SCR, 1/4-20 X 3/4 HHCS
13
86010780
17
WASHER, 1/4 SPLIT LOCK
14
86010790
6
WASHER, 3/8 SPLIT LOCK
15
86279510
6
WASHER, 3/8 X 1 FLAT NP
16
86043150
2
ASSEMBLY, HEATER CORE SS
17
86177060
2
CLAMP, HOSE #8 SST
18
86318840
1
ASSY, HEATER CORE COPPER, GT
19
86308840
1
HSG, VAC HE BOX
20
86308920
1
PLATE, HEATER CORE COVER
21
86308930
1
GASKET, HEATER CORE COVER
22
86310660
1
PNL, DIVERTER
23
86313690
1
GASKET, HEATER CORE COVER
24
86313730
1
PLATE, HEATER CORE COVER
