Prochem Legend GT User Manual
Page 65
63
86313050 LEGEND GT
Vacuum Pump
REF
PART NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES
1
86273320
1
SCR, CAP 7/16-14 x 4 HXHD
2
86273420
1
SCR, CAP 3/8-16x3 ALL THD
3
86273440
3
SCR, MACH 5/16-18 X 1" GR8
4
86177010
3
CLAMP, HOSE #48
5
86193230
1
SPRING, VAC REL VLV
6
86177640
2
CONN, 1/8P X 1/4POLY BR
7
86373920
1
BLOWER, BI-LOBE, DUAL SPLASH
8
86179580
1
DIAPHRAM, VAC REL VLV
9
86185320
1
HUB, P1 X 7/8
10
86191030
1
PULLEY, 2TA54
11
86371980
2
BELT, BANDO AX41 PWR KING COG
12
86180600
1
ELL, VAC REL VLV
13
86188500
1
NIP, VAC EXH OUTL
14
86005690
2
NUT, 3/8-16 HEX JAM
15
86271070
2
NUT, 7/16-14 HEX
16
86005770
4
NUT, 3/8-16 HEX NYLOCK
17
86279510
6
WASHER, 3/8 X 1 FLAT NP
18
86373900
1
BRKT, FRONT BLWR MTG, LGT
19
86311490
1
TUBING, FLEX, BLWR TO MFLR
20
86311600
1
WASHER, VAC REL VLV, #4VAC
21
86373910
1
BRKT, REAR BLWR MGT, LGT
22
86277830
1
SCR, 3/8-16 X 2" HXHD
23
86177430
1
CLMP, 1-1/16 ID X 3/8 BLT
24
86010790
1
WASHER, 3/8 SPLIT LOCK PLTD
25
86006920
1
SCREW, 3/8-16 X .75 HHCS STL GR5 ZNPLT
26
86310690
2
WASHER, 3/8 X 1 X .125 FLT SS
27
86190700
1
PMP, VAC 4M-L
28
86309350
1
BRKT, BLOWER MTG
29
86315540
1
BRKT, REAR BLOWER MTG
-
86318420
1
OIL, TUTHILL PNEULUBE
NOT SHOWN
-
86368270
1
VENT PLUG, 3/8" NPT, 5L359
NOT SHOWN
