WATER TANK, DUAL WITH DEMAND PUMP-OPTIONAL
EVEREST 980086 06/26/03
5-70
REF
PART NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
-
66-945260
-
TANK, DUAL SADDLE W/DMD PUMP
COMPLETE
-
66-945265
-
SINGLE SADDLE TANK W/DMND PMP
COMPLETE
1
50-501774
4
HOLD DOWN, SADDLE TANK GRAY
2
87171
16
WASHER, 3/8 FLAT
3
87163
16
WASHER 3/8 SPLIT LOCK
4
00-000072
16
SCR, 3/8-16 X 2’ HXHD
5
11-800432
4
CAP, WATER BOX
6
11-800041
2
ELL, STREET 1/2 BR
7
12-800278
4
FTTG, BRB 1/2P X 3/4H BR
8
03-000113
4
CLAMP, HOSE #12 SST
9
09-805456
1
HOSE, WTR 3/4 X 96”
10
11-800085
1
TEE, 1/2 BRASS
11
56-502000
2
ASSY, BASE SADDLE TANK GRAY
12
58-500661
2
MOLDING, WATER TANK
13
11-800168
2
PLUG, 1/2 BRASS HXHD
14
50-500511
1
PLATE, INSTALL MT
15
57119
9
NUT, 3/8-16 HEX NYLOCK
-
41458
1
SHLR, CHEM, 10-GAL JUG
NOT SHOWN
