LINE FILTER SK CIF-340-60

Part No. 276997081

Overvoltage filter – CSA filter

Technical characteristics:

Voltage limitation filter pursuant to CSA 22.2 No. 14-5 / UL508C Ch. 48 for reduction of
a 5 kV surge pulse (rising edge 1.2 µs/trailing edge 50 µs) to max. 300% of the
amplitude of the rated voltage (3x400 VAC/3x460 VAC/3x480 VAC/3x500 VAC for
SK CIF 340-60).

We recommend using line filter SK CIF-340-60 in combination with a line choke only.
The permanent current flowing through the choke must not be less than the resulting
typical input current of the connected frequency inverter(s).

CAUTION!

Note
With the use of a line choke, the effective input currents of the frequency inverters reduce to

approximately the values of the output currents, depending on inductance and load. Several
frequency inverters can be connected to a choke/filter combination. When doing so, the sum of input

currents must not exceed the rated/nominal current of the filter and/or the choke.

Area of application:



Frequency inverter

SK 5xxE-550-340-A … SK 5xxE-222-340-A

SK 2xxE-550-340-A … SK 2xxE-751-340-A

It is also possible to connect several frequency inverters to an appropriate filter. In this case, the resulting typical input current
(see technical data of FI) is definitive.

Technical parameters:



Rated voltage

[V]

3~ 380 -20% … 500 +10%

Mains voltages

[V]

3~ 400 / 3~ 460 / 3~ 480 / 3~ 500

Rated frequency

[Hz]

47 – 63

Rated current (FLA)

[A]

60 (max.) (input/output current)

max. line fuse

[A]

100*

Weight [kg]

0,71

Protection class

IP 20

Ambient temperature

[°C]

0 … +50

Operating mode

S1 – 100% duty cycle

Certifications

CE; cURus; RoHS

* Class, type and rating of fuse according to connected frequency inverters
