Technical information / datasheet, Sk pot1-1

Technical Information / Datasheet
Control box
SK POT1-1
1.0
Erstausgabe / first issue
3313
Rck
TI 278910120
GB
version
reason for change(s)
issue
name
document
speech
Pos : 1 /T ec hnis che Inf or mationen/ Bedi enboxen [SK POT 1-.. .]/ SK POT 1-1 / 278910120 / Basisinfor mationen [ SK POT1- 1] @ 3\ mod_1367329910096_388. doc x @ 64457 @ 555 @ 1
SK POT1-1
Part number: 278 910 120
Control Box / Manual control unit
Scope of supply
1 x
Control box
SK POT1-1
Incl. connection cable
open cable ends
1 x
Cable gland
M16
Field of use
Manual control unit (wall mounting possible) for the control of NORD frequency inverters with an
enable signal and setpoint value. It is designed for permanent connection to the frequency inverter.
According to the inverter type, appropriate interfaces are available, or are available as options.
Technical Data
Temperature range
0 °C … 40 °C
Connection cables
approx. 3 m long
Protection class
IP66
Weight
approx. 1.0 kg
Direction selector switch
Left - OFF - Right
Dimensions [mm]*
L x W x H: 120 x 80 x 80
Potentiometer
0 … 100 % (0 …10 V)
