EtherCAT Bus module – SK TU4-ECT-C
4
TI 275281167 - 4913
Schematic diagram - electrical connection
(Terminal designation on example of NORD frequency inverter SK 180E … SK 2xxE)
SK TI4-TU4 BUS
SK 180E … SK 2xxE
VI 24V
GND/0V
SYS +
SYS -
24V
GND/0V
SYS +
SYS -
Pos : 16 /T echnisc he I nf ormati onen/ SK xU x - Bus - Erweit erungen/ Et herC at/ Konfig urati on [ SK TU4- ECT(-C)] @ 3\ mod_1371803549598_388. doc x @ 79327 @ 5 @ 1
Configuration
In general, no settings need to be made on the device. However, via the "Hot Connection Group"
functionality, the module can be configured with a fixed address, the so-called "Second Address". This
is carried out via the DIP switches of the module. The DIP switch settings are read after a "Power On"
of the module.
.
DIP switch
Meaning
12
11
10
9
8
7
6
5
4
3
2
1
Address
0
0
0
0
0
0
0
0
0
0
0
X
0
0
0
0
0
0
0
0
0
0
0
1
X
1
0
0
0
0
0
0
0
0
0
1
0
X
2
-
-
-
-
-
-
-
-
-
-
-
X
-
1
1
1
1
1
1
1
1
1
1
1
X
2047
0
System bus
terminating resistor
not set
1
System bus
terminating resistor
set
Pos : 19 /T echnisc he I nf ormati onen/ SK xU x - Bus - Erweit erungen/ Et herC at/ LED Anz eigen [ SK TU4- ECT(-C)] @ 3\mod_1371804043826_388.doc x @ 79352 @ 5 @ 1
LED displays
The operating statuses of the module are visualised using LED indicators.
No.
Name
Colour
Meaning
1
RUN
green
Ethernet State
ERR
red
Ethernet Error
DS
green
Device status
DE
red
Device error
2
Link/Act
green
Link/Activity
Pos : 20 /T echnisc he I nf ormati onen/ SK xU x - Bus - Erweit erungen/ Et herC at/ LED Anz eigen- EtherCAT spezifis che LED [ ECT Allgemei n] @ 3\ mod_1371732026091_388. doc x @ 79187 @ @ 1
1
…
12
ON
OF
F
