EtherNet/IP Bus module – SK TU4-EIP
2 TI 275281119 - 4913
Digital input - working area Low: 0 V … 5 V, High: 15 V … 30 V
Digital input - specific data R
i
= 10 kΩ, input capacity: 10nF, reaction time 1 ms, inputs
according to EN 61131-2 type 1
Digital output - 24 VDC power supply
≤ 400 mA (input)
Digital output - working area Low = 0 V, High = 24 V; max. 200 mA
Bus specification
EtherNet/IP Max. 100 MBaud Cable Min. Ethernet CAT-5
Electrical isolation 500 V
eff
Max. cable length 100 m between two
modules
Bus connection 2 x M12 Shield via M12 direct to PE
Bus termination Takes place automatically PE connection via PE screw connection
Status display 8 LEDs in the terminal box
Topology* Star*, ring, linear bus
* additional switch for "star" topology required
Performance
Update interval for process data between module and frequency inverter
≤ 5 ms
Parameter read access to frequency inverter
≈ 15 ms
Parameters write access with storage on EEPROM
≈ 25 ms
Cycle times
≥ 1ms
Pos : 6 /T ec hnis che Inf or mationen/ SK xU x - Bus - Er wei ter ung en/ Et herNet /I P/Mer kmale [ EI P Allgemein] @ 3\ mod_1362996549668_388.doc x @ 61397 @ 5 @ 1
Module features
IO messages (process data connections) One "Exclusive Owner“
Max. 2 “Listen Only” connections
Type "Cyclic", min cycle time 1 ms
Explicit messages Yes
UCMM Supported
DLR Supported
Switch with two ports integrated
Addressing via DIP switches, module parameters, BOOTP and DHCP
possible
Access for NORD diagnosis tool via diagnosis socket on the device (if available) and possibly
via frequency converter and
Ethernet protocols UDP or TCP/IP
Pos : 7 /T ec hnis che Inf or mationen/ SK xU x - Bus - Er wei ter ung en/ Allgemein - Sys temübergreif end/M ont age [ SK TU 4- xxx- xxx] @ 2\mod_1353315135994_388. doc x @ 51251 @ 5 @ 1
Installation
The module must be attached to the suitable connection unit (SK TI4-TU- …) and connected using the
four M4 x 40 mm provided hexagon socket collar screws. Installation details can be found in the data
sheet for the relevant connection units.
