Aspire Digital 6935G - Manual (Page 47)

Chapter 1 39
LCD Inverter
AC Adaptor
System Power Management
Viewing Angle (degree)
Horizontal: Right/Left
65/65
Vertial: Upper/Lower
50/50
Temperature Range(°C)
Operating
0 to +50
Storage (shipping)
-20 to +60
Item Specification
Vendor & model name TDK
Brightness conditions N/A
Input voltage (V) 9~20V
Input current (mA) 360mA (max)
Output voltage (V, rms) 710V (1800V for kick off)
Output current (mA, rms) 6.5mA (max)
Output voltage frequency (k Hz) 58 KHz (max)
Item Specification
Input rating 100V AC to 240V AC, 47Hz to 63Hz
Maximum input AC current 1.5A
Inrush current 50A@115VAC
100A@230VAC
Efficiency 85% min. @115VAC input full load
ACPI mode Power Management
Mech. Off (G3) All devices in the system are turned off completely
Soft Off (G2/S5) OS initiated shutdown. All devices in the system are turned
off completely
Working (G0/S0) Individual devices such as the CPU and hard disc may be
power managed in this state
Suspend to RAM (S3)
CPU set power down
VGA Suspend
PCMCIA Suspend
Audio Power Down
Hard Disk Power Down
CD-ROM Power Down
Super I/O Low Power mode
Save to Disk (S4) Also called Hibernation Mode. System saves all system
states and data onto the disc prior to power off the whole
system
Item Specification
