Characterized with an aluminum target 2U 4U 9U 12U 16U 26U 38U 51U
Offset inch 0.002 0.005 0.010 0.016 0.020 0.032 0.050 0.100
(mm) (0.05) (0.13) (0.25) (0.40) (0.50) (.80) (1.20) (2.50)
Short Range inch 0.010 0.025 0.050 0.080 0.100 0.160 0.250 0.300
(mm) (0.25) (0.60) (1.25) (2.00) (2.50) (4.00) (6.00) (7.5)
Standard Range inch 0.020 0.050 0.100 0.160 0.200 0.320 0.500 0.600
(mm) ('0.50) (1.30) (2.50) (4.00) (5.00) (8.00) (12.0) (15.0)
Extended Range inch 0.030 0.070 0.150 0.240 0.320 0.500 0.800 1.000
(mm) (0.75) (1.75) (3.75) (6.00) (8.00) (12.5) (20.0) (25.0)
Typical Specifications for stardard range, aluminum target, standard cable length
Nonlinearity 6 pt calibration ±%FS <0.3%
Nonlinearity 21 pt calibration ±%FS <0.1%
Static Resolution RMS%FS <0.001%
Resolution @ 100 Hz RMS%FS <0.01%
Resolution @ 1000 Hz RMS%FS <0.02%
Thermal Sensitity %FS°F 0.05
(%FS°C) (0.1)
Thermal Sensitity w/temp %FS°F 0.01
comp calibration (%FS°C) (0.02)
Probe Specifications
