APPENDIX A: COMMAND LIST
The following are the low level commands for the user to program an interface. Many of the
setup commands are read or write. The command starts with an 'S' for a write (such as SCLL
20000) or an 'R' for a read (RCLL will read back the setting). Settings are stored in non-volatile
system memory.
Command Passlevel
Required
Parameters Returns Comments
Monitor Commands
MD NONE NONE Distance Output Monitor Distance Output 100000=100%
ML NONE NONE Monitor Limit Monitor Limit 0= in range 1=low 2 = hi
MR NONE NONE Monitor Relay Monitor Relay 0= Open 1 = Closed
AutoZero Function
ZZ NONE NONE -- Zeroes the output
ZC NONE NONE -- Clears the zero on the output
Limit Setup
S(R)CLP x USER X = polarity Polarity SET(READ) Limit Polarity 0 = NO 1= NC
S(R)CLH xxxx USER xx = Hi Limit Hi Limit SET(READ) Limit Hi (Signed Long Int)
S(R)CLL xxxxx USER xx = Lo Limit Lo Limit SET(READ) Limit LO (Signed Long Int)
S(R)CLD xxxx USER xx = Hysteresis Hysteresis
SET(READ) Limit Deadband (Hysteresis)
(Signed Long Int)
Ethernet Setup
S(R)EA xxx xxx xxx xxx USER
xx xxx xxx xxx =
IP Address
IP Address
SET(READ) Ethernet IP Address
Note: Separate Octets with spaces not '.'
S(R)EW xxxxx USER xx = port UDP Writer Port SET(READ) Ethernet Writer Port
S(R)ER xxxxx USER xx = port UDP Reader SET(READ) Ethernet Reader Port
REM NONE MAC READ Ethernet MAC Address
Output Setup
S(R)UI x USER x = setting Setting
SET(READ) User Current Output
0=0-20mA
1=4-20mA
S(R)UV x USER x = setting Setting
SET(READ) User Voltage output
0=0-5V
1 =+/-5V
2=0-10V
3=+/-10V
