AUTOMATED VALVE DRAWINGS
W/ ELECTRIC ACTUATOR
E
D
C F
B
SIZE
G
6
2
W/ PNEUMATIC ACTUATOR
E
D
C
F
B
SIZE
G
W/ EXPLOSION-PROOF ELECTRIC ACTUATOR
E
D
C
F
B
SIZE
G
OPEN
Page 3
Size
B
C
D
E
F
G
1/2˝
4-7/8˝
124.5 mm
2-3/8˝
60.5 mm
4-5/8˝
118 mm
4-1/2˝
116 mm
1-3/8˝
36.5 mm
3-5/8˝
91.6 mm 3/4˝
5˝
128 mm
2-3/8˝
60.5 mm
5˝
127 mm
4-1/2˝
116 mm
1-3/8˝
36.5 mm
3-7/8˝
98.6 mm 1˝
6˝
151 mm
2-3/4˝
71 mm
6˝
152.4 mm
5-3/4˝
145 mm
1-5/8˝
41 mm
4-5/8˝
117.8 mm 1-1/2˝
6-1/2˝
164 mm
2-3/4˝
71 mm
6-7/8˝
175 mm
5-3/4˝
145 mm
1-5/8˝
41 mm
5-1/2˝
139.6 mm 2˝
7-1/2˝
190 mm
3-1/4˝
82 mm
7-1/2˝
190 mm
6-5/8˝
169 mm
1-7/8˝
46 mm
6-3/8˝
160.6 mm
Double Acting Pneumatic Actuator
Size
B
C
D
E
F
G
1/2˝
5-3/8˝
136.5 mm
2-3/4˝
71 mm
4-5/8˝
118 mm
5-3/4˝
145 mm
1-5/8˝
41 mm
3-5/8˝
91.6 mm 3/4˝
5-1/2˝
140 mm
2-3/4˝
71 mm
5˝
127 mm
5-3/4˝
145 mm
1-5/8˝
41 mm
3-7/8˝
98.6 mm 1˝
6-5/8˝
167 mm
3-1/4˝
82 mm
6˝
152.4 mm
6-5/8˝
169 mm
1-7/8˝
46 mm
4-5/8˝
117.8 mm 1-1/2˝
7-1/8˝
180 mm
3-1/4˝
71 mm
6-7/8˝
175 mm
6-5/8˝
169 mm
1-7/8˝
46 mm
5-1/2˝
139.6 mm 2˝
8-1/8˝
208 mm
3-3/4˝
94 mm
7-1/2˝
190 mm
7-7/8˝
201 mm
2˝
52 mm
6-3/8˝
160.6 mm
Spring Return Pneumatic Actuator
Size
B
C
D
E
F
G
1/2˝
5-3/4˝
147 mm
4-1/2˝
113 mm
4-5/8˝
118 mm
6-1/4˝
160 mm
3˝
77 mm
3-5/8˝
91.6 mm 3/4˝
5-7/8˝
150.5 mm
4-1/2˝
113 mm
5˝
127 mm
6-1/4˝
160 mm
3˝
77 mm
3-7/8˝
98.6 mm 1˝
6-3/8˝
161.5 mm
4-1/2˝
113 mm
6˝
152.4 mm
6-1/4˝
160 mm
3˝
77 mm
4-5/8˝
117.8 mm 1-1/2˝
6-7/8˝
174.5 mm
4-1/2˝
113 mm
6-7/8˝
175 mm
6-1/4˝
160 mm
3˝
77 mm
5-1/2˝
139.6 mm 2˝
7-1/4˝
184.5 mm
4-1/2˝
113 mm
7-1/2˝
190 mm
6-1/4˝
160 mm
3˝
77 mm
6-3/8˝
160.6 mm
NPT
B
C
D
E
F
G
1/2˝
8-1/8˝
207 mm
9-3/8˝
238.9 mm
4-5/8˝
118 mm
8-1/2˝
216.7 mm
5˝
125.8 mm
3-5/8˝
91.6 mm 3/4˝
8-1/4˝
210 mm
9-3/8˝
238.9 mm
5˝
127 mm
8-1/2˝
216.7 mm
5˝
125.8 mm
3-7/8˝
98.6 mm 1˝
8-3/4˝
221.3 mm
9-3/8˝
238.9 mm
6˝
152.4 mm
8-1/2˝
216.7 mm
5˝
125.8 mm
4-5/8˝
117.8 mm 1-1/2˝
9-1/4˝
234.3 mm
9-3/8˝
238.9 mm
6-7/8˝
175 mm
8-1/2˝
216.7 mm
5˝
125.8 mm
5-1/2˝
139.6 mm 2˝
9-5/8˝
244.3 mm
9-3/8˝
238.9 mm
7-1/2˝
190 mm
8-1/2˝
216 mm
5˝
125.8 mm
6-3/8˝
160.6 mm
