VALVE BILL OF MATERIALS
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14 Description
Body
Cap
Ball
Ball Seat
Gasket
Thrust Washer
Stem Packing
Ring
Bevel Washer
Stop Pin
Nut
Stem
Handle
Prevailing Device Material
ASTM A351-CF8M
PTFE
PTFE
AISI 304
AISI 301
AISI 316
AISI 304
AISI 316
AISI 304
Model
Number
WE33-CHD00-L
WE33-DHD00-L
WE33-EHD00-L
WE33-GHD00-L
WE33-HHD00-L
WE33-CHD00-T
WE33-DHD00-T
WE33-EHD00-T
WE33-GHD00-T
WE33-HHD00-T
ØA
3/8˝
(9.4)
5/8˝
(15.8)
7/8˝
(22.1)
1-26/64˝
(35)
1-7/8˝
(47.6)
3/8˝
(9.4)
5/8˝
(15.8)
7/8˝
(22.1)
1-26/64˝
(35)
1-7/8˝
(47.6)
H2
in(mm)
1-3/4˝
(44.50)
1-57/64˝
(48)
3-15/64˝
(59)
2-27/32˝
(72)
3-15/64˝
(59)
1-3/4˝
(44.50)
1-57/64˝
(48)
3-15/64˝
(59)
2-27/32˝
(72)
3-15/64˝
(82)
M1
M12x1.75
M12x1.75
M14x2.0
M18x2.5
M18x2.5
M12x1.75
M12x1.75
M14x2.0
M18x2.5
M18x2.5
Cv
(gal/min)
14.39
42.25
86.17
223.61
437.98
14.39
42.25
86.17
223.61
437.98
VALVE DIMENSIONAL DRAWING
13
14 12
11
10 9
8
7
6
5
2 1 3 4
VENTED BALL
M1
H
H1
ØA1
ØA
W
R
ØRb
ØRa
ØD1
ØD2
L
H2
POPULAR MODELS
Page 2
Size
1/2˝
3/4˝
1˝
1-1/2˝
2˝
1/2˝
3/4˝
1˝
1-1/2˝
2˝
ØA1
in(mm)
1˝
(25.4)
1˝
(25.4)
1-63/64˝
(50.4)
1-63/64˝
(50.4)
2-33/64˝
(63.9)
1˝
(25.4)
1˝
(25.4)
1-63/64˝
(50.4)
1-63/64˝
(50.4)
2-33/64˝
(63.9) ØD1
in(mm)
1-27/64˝
(36)
1-27/64˝
(36)
1-27/64˝
(36)
1-31/32˝
(50)
1-31/32˝
(50)
1-27/64˝
(36)
1-27/64˝
(36)
1-27/64˝
(36)
1-31/32˝
(50)
1-31/32˝
(50) ØD2
in(mm)
1-21/32˝
(42)
1-21/32˝
(42)
1-21/32˝
(42)
2-3/4˝
(70)
2-3/4˝
(70)
1-21/32˝
(42)
1-21/32˝
(42)
1-21/32˝
(42)
2-3/4˝
(70)
2-3/4˝
(70)
ISO
F03/04
F03/04
F03/04
F05/07
F05/07
F03/04
F03/04
F03/04
F05/07
F05/07
S
in(mm)
23/64˝
(9)
23/64˝
(9)
7/16˝
(11)
9/16˝
(14)
9/16˝
(14)
23/64˝
(9)
23/64˝
(9)
7/16˝
(11)
9/16˝
(14)
9/16˝
(14) ØRa
in(mm)
7/64˝
(2.75)
1/8˝
(3)
9/64˝
(3.5)
9/64˝
(3.5)
9/64˝
(3.5)
7/64˝
(2.75)
1/8˝
(3)
9/64˝
(3.5)
9/64˝
(3.5)
9/64˝
(3.5) ØRb
in(mm)
7/64˝
(2.75)
1/8˝
(3)
9/64˝
(3.5)
3/16˝
(4.5)
3/16˝
(4.5)
7/64˝
(2.75)
1/8˝
(3)
9/64˝
(3.5)
3/16˝
(4.5)
3/16˝
(4.5) L
in(mm)
4-1/32˝
(118)
5˝
(127)
6˝
(152.4)
6-57/64˝
(175)
7-1/2˝
(190)
4-21/32˝
(118)
5˝
(127)
6˝
(152.4)
6-57/64˝
(175)
7-1/2˝
(190) W
in(mm)
4-49/64˝
(122)
4-49/64˝
(122)
5-13/32˝
(137)
7-11/64˝
(183)
7-11/64˝
(183)
4-49/64˝
(122)
4-49/64˝
(122)
5-13/32˝
(137)
7-11/64˝
(183)
7-11/64˝
(183) H
in(mm)
3-5/64˝
(78)
3-15/64˝
(82)
3-35/64˝
(90)
4-11/32˝
(110)
4-33/64˝
(114.7)
3-5/64˝
(78)
3-15/64˝
(82)
3-35/64˝
(90)
4-11/32˝
(110)
4-33/64˝
(114.7) H1
in(mm)
23/64˝
(9)
23/64˝
(9)
7/16˝
(11)
9/16˝
(14)
9/16˝
(14)
23/64˝
(9)
23/64˝
(9)
7/16˝
(11)
9/16˝
(14)
9/16˝
(14)
Port
L
L
L
L
L
T
T
T
T
T
Size
1/2˝
3/4˝
1˝
1-1/2˝
2˝
Cv
(gal/min)
14.39
42.25
86.17
223.61
437.98 Hand Operated
Model
WE33-CHD00-T2
WE33-DHD00-T2
WE33-EHD00-T2
WE33-GHD00-T2
WE33-HHD00-T2 Double Acting
Pneumatic Model
WE33-CDA01-T2
WE33-DDA01-T2
WE33-EDA02-T2
WE33-GDA02-T2
WE33-HDA03-T2 Spring Return
Pneumatic Model
WE33-CSR02-T2
WE33-DSR02-T2
WE33-ESR03-T2
WE33-GSR03-T2
WE33-HSR04-T2
NEMA 4X Two
Position Electric
(110 VAC) Model
WE33-CTD01-T2-A
WE33-DTD01-T2-A
WE33-ETD01-T2-A
WE33-GTD02-T2-A
WE33-HTD02-T2-A NEMA 4X
Modulating Electric
(110 VAC) Model
WE33-CMD01-T2-A
WE33-DMD01-T2-A
WE33-EMD01-T2-A
WE33-GMD02-T2-A
WE33-HMD02-T2-A
