Crystal MultiCal KPA/PSI - Manual (Page 6)

PN: 1763 Rev C, 4/2004
Page 6 of 8 PRESSURE is Our BUSINESS ™
Pressure
Range Accuracy
0 to 200 kPa ±(0.05% of Reading + 0.1″H
2
O)
0 to 30 PSI ±(0.05% of Reading + 0.01PSI)
30 to 50 PSI ±(0.25% of Reading)
0 to -100kPa ±(0.5% of Reading + 0.14 kPa)
0 to -14.7 PSI ±(0.25% of Reading), typical
Maximum Working Pressure: 100 PSI
Burst Pressure: 500 PSI
Wetted Materials: 316 Stainless Steel, PTFE impregnated hard
anodized aluminum, and buna-n rubber.
Unless otherwise specified at time of purchase: 1 PSI = 27.6806″H
2
O (water at 4°C)
Operating Environment
Temperature Range Humidity
-10 to 10°C Uncontrolled Humidity
10 to 30°C 0 to 95% Relative Humidity
30 to 40°C 0 to 75% Relative Humidity
40 to 50°C 0 to 45% Relative Humidity
50 to 55°C 0 to 35% Relative Humidity
Temperature Derating
Add to Basic Accuracy Specification. °C = ambient temperature.
Temperature Range Derating
28 to 55°C (0.016%/°C) x (°C - 28°C)
18 to 28°C No Derating
0 to 18°C (0.048%/°C) x (18° - °C)
-10 to 0°C (0.264%/°C) x (9° - °C)
General Specifications
Weight 164 grams (5.8 oz.) w/battery
Overall length 118mm (4 5 /
8
″)
Battery NEDA#1604, 6F22, 006P
Battery Life 400 Hours typ. w/alkaline battery
Output 1mV/unit into 10MΩ load
Storage -51°C to 71°C
European Community Declaration of Conformity
EC Declaration of Conformity
I/We
Crystal Engineering Corporation
of
720 Aerovista Place, Suite B
San Luis Obispo, CA, 93401
USA
declare that
Pressure Module
MultiCal Series (All Versions)
In accordance with the following directives
89/336/EEC The Electromagnetic Compatibility Directive
and its amending directives
has been designed and manufactured to the following specifications
EN 61326-1:2002 Conducted Emissions Class A N/A
EN 61326-1:2002 Radiated Emissions Class A Pass
EN 61000-3-2:1995 Current Harmonic Emissions Class A N/A
EN 61000-3-3:1995 Voltage Variations & Flicker N/A N/A
EN 61000-4-2:2002 Electrostatic Discharge Pass
EN 61000-4-3:2002 Radiated EM Field Pass
EN 61000-4-4:2002 Electrical Fast Transient/Burst N/A
EN 61000-4-5:2002 Surge Immunity N/A
EN 61000-4-6:1994 RF Conducted Disturbances N/A
EN 61000-4-8:1994 Power Magnetic Field N/A
EN 61000-4-11:1994 Voltage Dips and Interruptions N/A
Note: Product is battery operated.
I hereby declare that the equipment named above has been designed to comply with the
relevant sections of the above referenced specifications. The unit complies with all essential
requirements of the Directives
David K. Porter, P.E.
(NAME OF AUTHORIZED PERSON)
Director of Engineering
(TITLE OF AUTHORIZED PERSON)
16 July 2003
(SIGNATURE OF THE AUTHORIZED PERSON) (DATE OF ISSUE)
