Overview
2
GaugeCalHP Comparator Operation Manual
FEATURES AND PARTS LISTS
Each comparator includes a fine adjust for precise pressure adjustments. The reference indicator threads directly to the CPF Male fitting. The device under test
connects to the supplied 1/4” Female NPT fitting. For more sizes see the
and the
Parts Included with the GaugeCalHP
Part Number
Description
—
CPF Male Fittings (2)—non-removable
MPF15K-1/4FPT
1/4" Female NPT Fitting (1)
5102
Fine Adjust (installed)
Removable Handle Assembly
For transport. Includes captive screw.
Fine Adjust
Easy to use, even at 15000 psi.
Brackets
For easy mounting to a table top.
No Mess Drip Tray
Captures fluid from bleeding the system.
Relief Valve
Pivot Manifold
Manifold rotates for testing large size gauges.
Connection Fitting
With easy alignment swivel capability.
Reservoir
Clear, removable reservoir with a fill line.
Travel Indicator
Shows the amount of stroke available.
