Settings
9
Confi gXP User’s Manual
Using the User Units Wizard
The User Units Wizard operates in two modes: Linear Fit or Tank Level. Both modes calculate an optimum User Factor and User Off set.
The Linear Fit tab
The
Linear Fit
tab allows you to quickly calculate the best User Factor and User Off set by entering actual measurements and the corresponding desired read-
ing for each measurement. In each row, enter the displayed pressure in the fi rst column and the reading you want the gauge to display in the
Desired Indica-
tion
column. The User Factor and User Off set will be recalculated after each point entered. The
Gauge Reading
column shows what the gauge will actually
display using the calculated User Factor and User Off set. The
Delta
column indicates how much error there is between the Desired Indication and the Gauge
Reading.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
