USER GUIDE LCD PANEL
20
DISPLAY UNIT
Full color (RGB) unit connecting directly to external video sources.
SIZE 310 x 310 x 40 mm
12.2 x 12.2 x 1.6 inch
WEIGHT 1700 grams / 3.8 lbs
POWER -5, -12, 5 V
LCD CELL Active matrix TFT stripe configuration
COLOR
RESOLUTION 16.7 million colors
RESPONSE TIME 30 ms
CONTRAST RATIO 100:1
PIXEL RESOLUTION 640 x 480 x 3 (RGB)
SCREEN DIAGONAL 8.4 "
VIDEO FREQUENCY 25 ~ 35 MHz
HORIZONTAL
SYNC 15 ~ 40 kHz
VERTICAL SYNC 60 ~ 76 Hz (VGA)
66 Hz (MACII)
50 ~ 60 Hz (VIDEO)
NTSC SYSTEM M, 4.43 NTSC
PAL SYSTEM B, G, H, D, I
SECAM SYSTEM B, G, H, D, I, K1, L
COMPUTER INPUT 0 ~ 0.7 Vpp
VIDEO INPUT 0 ~ 0.7 Vpp
S-VIDEO INPUT 0 ~ 0.7 Vpp
DEFECTIVE PIXELS Maximum 25 (black, red, green or blue)
APPROVALS FCC, Class A, Subpart J, Part 15
